Dehumidifying Heating and Cooling Unit

Applications: ideal for high and large space (H: 4-30m) that needs cooling, heating and dehumidifying.

Model: AirTS-DK-I, AirTS-DK-II

Function: cooling, heating, dehumidifying

Cold and hot source: cold water (7-12℃) /hot water (40-90℃)/steam (<120℃)

Control mode: wireless control, variable frequency, auto monitoring

Quality Assurance

Stable and Durable.

After-sales Service

24H Online.

Inquire Now Next Product

Working Principle Specification Application Download Inquire Now

Working Principle

When hot/cold water or stream passes the equipment, the efficient heat exchanger in the equipment is used to achieve rapid heating/cooling of the air.

The large wind pressure axial flow fan installed on the top is used to forcedly press the hot/cold air down. Then the air is subject to pressure boost twice through the silencer sponge and the lower trapezoidal convergence, swirls out from the nozzle through the guide vane and is distributed throughout the space from top to down.

Features

By adjusting wind speed and air outlet angle, it achieves comfortable cooling or heating environment

Supply air angle stepless regulation

Utilize axial fan to efficiently recover heat from the top space, reducing heat loss from the roof, achieving energy-saving effects

The fan is installed below the air exchanger to control noise level (<60 dB)

The special designed square-shaped type air exchanger prevent the leakage of condensate water

The complex designed air exchanger, 1.5 times exchange area than others, takes significant heating efficiency

The air supply distance is long, and the hot air volume is high

4 sides return air structure, installed on the roof, require smaller installation space

Function: cooling, heating, dehumidifying

Functions

Fall prevention warning monitoring

Working data collection and analysis

Variable air volume and water volume

Wireless intelligent control

Filter net self-cleaning

Frost protection

Dehumidifying function

Light breeze air supply

AirTS top unit

High and large space air conditioner lifted on the roof

It achieves hot/cold air from the air exchanger in the equipment

It distributes hot/cold air by means of efficient air distributor, which eliminates the undesirable indoor temp layers

Comfortable cooling or heating environment without wind feeling sense

Specification

Dehumidifying Heating and Cooling Unit

Dehumidifying Heating and Cooling Unit
Model		AirTS-DK-I	AirTS-DK-II
Rotating speed of fan	r/min	0～900	0～860
Standard circulating air volume	m³/h	0～5800	0～8500
Voltage	V	380±5%	380±5%
Electric power	kW	0～0.85	0～1.80
Current	A	0～1.65	0~3.60
Suitable installation height	m	4~13	4~21
Control mode		VAV stepless regulation	VAV stepless regulation
Noise	dB	<60	<60

Dehumidifying Heating and Cooling Unit

Dimension
Model		AirTS-DK-I	AirTS-DK-II
A	mm	900	1100
B	mm	1590	1734
C	mm	720	920
E	mm	100	100
F	mm	95	95
G	mm	480	568
H	mm	765	935
J	mm	997	1075
K	mm	1217	1323
L	mm	1457	1583
M	mm	617	703
N	mm	567	654
P (internal thread)	mm	DN25	DN32
Q (internal thread)	mm	DN40	DN50
R (external thread)	mm	DN25	DN32
Weight	kg	180	260
Water volume	L	12.9	18.1
